Brat 30A PWM Charge Controller | Midnite Solar

Midnite Solar’s Brat 30A PWM Charge Controller offers an impressive array of features compared to other PWM charge controllers for smaller PV systems. The Brat is a PWM charger engineered to exacting standards, offering up to 30A of charging current, and industry-leading lighting control, load control plus a singular Solar Clock you won’t find on other PWM charge controllers. Other notable features include an affordable price point, temperature-compensated charging, as well as manual / 30-day automatic equalization. The Brat 30A PWM Charge Controller is built rain-proof, making it well-suited for RV, marine as well as outdoor applications in remote areas where the unit might be left unattended for long periods. It also sports dead-battery charging and low-voltage load disconnect functionality. Brat 30A PWM Charge Controller Features & Benefits: 2 YEAR WARRANTY SELECTABLE CHARGING MODES: 20A charger with 10A load control / 30A charger without load control NO RELAYS, NO FANS, NO EXTERNAL HEAT-SINK TYPE 3R ENCLOSURE P/V INPUT VOLTAGE MAXIMUM – 60 volts LEDs: Four LED’s for Bulk, Float, Load On and Low Battery. Patterned blinking LED’s provide feedback about fault conditions. NOMINAL BATTERY VOLTAGE: 12 or 24V – Selectable 10 AMPS MAXIMUM LOAD CIRCUIT RATING LOAD CIRCUIT: A unique feature of the Brat is the load circuit. This versatile feature can be used for many purposes including running well pumps, electric fences, or billboard lights in remote areas. CUSTOMIZABLE LIGHTING CONTROLLER: The Brat sports a highly customizable 16 position rotary switch lighting controller. COMPACT DESIGN: We understand space can be a struggle in a boat or RV. With that in mind we kept the physical design of the Brat compact without sacrificing performance. SEALED FOR HARSH ENVIRONMENTS: All Brats are weather proof, sealed in a clear UV stabilized polycarbonate housing! (Type 3R/IP55). REPAIRABLE: Field repairable printed circuit board (by a qualified technician) Product Documentation spec_sheet_brat_ENDownload Brat-Instruction-Manual-ENDownload Brat 30A PWM Charge Controller Intro Video MidNite Solar Customer Support Related
